Product Details:
|
| Features: | Good Thermal Insulation Performance, Waterproof, Light Weight, Easy To Install | Product Name: | Silica Color Steel Plate |
|---|---|---|---|
| Brand Name: | Haike | Place Of Origin: | Chongqing, China |
| Core Material: | Silica Rock | Width: | 950mm/1150mm |
| Thickness Of Color Steel Plate: | 0.3-0.6mm | Thickness: | 50-200mm, 50/75/100/125/150mm |
| Length: | 1-11.8m | Density: | 40-80kg/m3 |
| Color: | Customer's Require | Fire Resistance Level: | A2 Class Fire Retardant Function |
| Panel Material: | Aluminum/ Color Steel/ Aluminum Manganese Magnesium/ Stainless Steel/ Galvanized Sheet | Function: | Thermal Insulation, Insulated Wall Panel |
| Heat Conductivity/Thermal Conductivity: | 0.022-0.04w/m.k | Usage: | Exterior Wall Partition |
| Advantage: | Eco-friendly | ||
| High Light: | Carved Silica Color Steel Sandwich Panel,Steel Sandwich Panel Metal Roofing 950mm,metal sandwich panel Roofing 1150mm Width |
||
Sandwich Metal Carved Wall Panel Silica Color Steel Sandwich Panel Metal Roofing
The silica rock color steel plate adopts a new method based on changing the structure of the polymer matrix to improve the foam performance. It is the interpenetrating network PN technology that attracts people's attention, which is a kind of polymer alloys that are interpenetrated and entangled with each other by two or more polymer networks.
Thermal insulation & Heat resistance
The thermal conductivity is only 0.022-0.040w (m.k), and the silica color steel plate can withstand high temperature of 250-300 ℃ for a long time, and can withstand high temperature of 400-500 ℃ in case of fire.
Flame retardant
Good flame retardancy, heat resistance, no smoke, no harmful gas.
Low toxicity and low smoke
There are only hydrogen, carbon and oxygen atoms in the silica rock color steel plate. When decomposed at high temperature, only products composed of carbon and oxygen can be produced, and there is no other toxic gas except a small amount of co.
Flame penetration resistance
Silica color steel plate has carbon formation, no drop, no curling and no melting phenomenon under the direct action of flame.
Wide range of use
The strength of silica rock color steel plate is not significantly affected by temperature. It does not experience cold shrinkage and cold brittleness at low temperature of -196 °C, and can be used for a long time in the range of -196 °C to 130 °C.
Product Parameters
|
item
|
value
|
|
Warranty
|
5 years
|
|
After-sale Service
|
Online technical support, Other
|
|
Project Solution Capability
|
graphic design, Others
|
|
Application
|
Apartment
|
|
Design Style
|
Modern
|
|
Place of Origin
|
China, Chongqing
|
|
Brand Name
|
Haike
|
|
Shape
|
Square
|
|
Material
|
Silica rock, metal
|
|
Core Material
|
Silica rock
|
|
Product Name
|
Silica color steel sandwich panels
|
|
Fire resistance level
|
A2 class fire retardant function
|
|
Thickness
|
50-200mm, 50/75/100/125/150mm
|
|
Thickness of color steel plate
|
0.3-0.6mm
|
|
Width
|
950mm/1150mm
|
|
Length
|
1-11.8m
|
|
Density
|
40-80kg/m3
|
|
Panel Material
|
Aluminum/ color steel/ aluminum manganese magnesium/ stainless steel/ galvanized sheet
|
|
Function
|
Thermal Insulation, Insulated Wall Panel
|
|
Advantage
|
Eco-friendly
|
