Product Details:
|
| Product Name: | Rock Wool Tube Basalt Hydrophobic | Density: | 60-150kg/m3 |
|---|---|---|---|
| Thickness: | 30-200mm | Length: | 1000mm |
| Inner Diameter: | 22-610mm | Levels: | A1 |
| Thermal Conductivity: | 0.034-0.044w/mk | Hydrophobic: | 98.2% |
| Core Material: | Rockwool | ||
| High Light: | ISO Rock Wool Thermal Insulation Tube,Rock Wool Tube Basalt Hydrophobic,ISO Rock Wool Tube Basalt Hydrophobic |
||
Thermal Pipe Thermal Insulation Rock Wool Tube Basalt Hydrophobic
Specification
| item | value |
| Warranty | 5 years |
| After-sale Service | Online technical support, Onsite Installation, Onsite Training, Onsite Inspection, Free spare parts, Return and Replacement, Other |
| Project Solution Capability | graphic design, total solution for projects, Cross Categories Consolidation, Others |
| Application | High temperature pipeline |
| Design Style | Industrial |
| Place of Origin | Chongiqng, China |
| Brand Name | Chongqing Haike |
| Model Number | Customized on demand |
| Type | Insulation pipe |
| Material | Rockwool |
| Product Name | Rock Wool Tube Basalt Hydrophobic |
| Density | 60-150kg/m3 |
| Thickness | 30-200mm |
| Length | 1000mm |
| Inner diameter | 22-610mm |
| Levels | A1 |
| Thermal Conductivity | 0.034-0.044w/mk |
| Hydrophobic | 98.2% |
| Thermal conductivity (room temperature) | 0.035 |
| Low temperature bending ≤ | 2.5% |
Products Description
Rock wool tube is a kind of rock wool insulation material mainly used in pipelines, which is based on natural basalt as the main raw material. After high temperature melting, it is made of artificial inorganic fiber by high-speed centrifugal equipment, and at the same time, special binder and dustproof oil are added, and then heated and solidified to make a variety of specifications and different requirements of rock wool insulation tube. At the same time, rockwool can also be combined with glass wool aluminum silicate wool to make rockwool composite insulation tube shell. Rock wool tube shell is made of resin rock wool insulation tube shell and waterproof rock wool insulation tube shell made of selected diabase and basalt slag as the main raw materials, which is melted at high temperature and sprayed into special adhesive and waterproof agent in the process of high-speed centrifugation.
Products Feature
1. Rock wool pipe system with selected basalt as the main raw material, by high temperature melting into artificial inorganic fiber, with light weight, small thermal conductivity, good sound absorption performance, non-combustible, good chemical stability, etc.
2. It is a new type of heat preservation, heat insulation, sound absorption material.
3. Rock wool tube also has waterproof, thermal insulation, thermal insulation and other properties, there is a certain chemical stability, even in the wet condition of long-term use will not occur delix.
4. Because its products do not contain fluorine (F-) and chlorine (CL), rock wool has no corrosion effect on equipment and is non-combustible material.
Application
Rock wool tube is widely used in petroleum, chemical, metallurgy, shipbuilding, textile and other industrial boiler and equipment pipeline insulation, but also used in the construction industry of partition wall, ceiling and internal and external wall insulation and various types of cold and hot pipes and hidden, exposed pipe insulation.
Electric power, petroleum, chemical, light industry, metallurgy and other industries of pipeline heat insulation is suitable for all kinds of pipeline heat insulation and heat insulation, especially for small straight pipeline construction convenient and rapid. Waterproof rock wool tube with moisture-proof, heat, hate water special function, especially suitable for use in rainy, humid environment, moisture absorption rate below 5 percent, water hate rate in 98 percent.
